Product Details:
Payment & Shipping Terms:
|
Capacity:: | 15kg-150kg | Loading Type: | Front Loading |
---|---|---|---|
Raw Material: | Stainless Steel 304 | Heating:: | Electric, Steam, Electric&Steam,Hot & Cold Water |
Automatic: | Automatic & Manual | Voltage: | 110v,220v,380v,400v,440v |
Packing: | Pallet Or Wooden Case | HS Code: | 84502000 |
Suspension: | Full Suspension Shock Structure | Door: | Front And Single |
High Light: | large capacity washing machine,heavy duty washing machine |
· Commercial Laundry Equipment
· Gamesail supply a wide range of commercial laundry equipment for industrial and commercial sectors, including washers, dryers, ironers and spare parts for most manufacturers and model ranges.
·VIEW OUR COMMERCIAL LAUNDRY EQUIPMENT RANGE
·
With a proud heritage as the leader in commercial laundry equipment services, along with a worldwide reputation for innovation, we strive to be your complete laundry solution for commercial laundry equipment and services.
· Our experienced industry insights, customer service and unrivalled research and development capabilities enable us to offer the most diverse range of commercial and industrial laundry equipment.
·
High Quality Commercial Laundry Equipment
· For many companies, laundry is a necessary but often overlooked requirement. After all, staff uniforms and all other garments need to be washed to be at their very best. This means many businesses and organisations, from hotels to education centres, need the right commercial laundry equipment to meet their needs.
· We understand the power of laundry equipment, which is why we offer a vast range of machines and appliances to suit all manner of companies. Gamesail has been providing companies with bespoke, quality laundry equipment since 2002 and we’ve been expanding ever since.
·
The Right Product For You
· Different companies have different needs, so the right appliance is essential. For example, traditional washing machines are great for handling large loads, while the likes of barrier washers can provide safe infection control services. If you’re not sure what you need, we can help you find the right tools for the job, choosing from our range of:
· Washing machines,
· Tumble dryers
· Barrier washers
· Ironers
· Folders
· Hydro extractors
· Cloth finishers
· Similarly, you also need to consider the size and dimensions of your work space. We have plenty of experience helping companies large and small. If you have space limitations, we can advise you right options, for instance, to help maximise the productivity and efficiency from every possible area.
·
The Power Of On-site Commercial Laundry Equipment
· If you haven’t invested in commercial laundry equipment yet, you may be wondering why it’s so beneficial. The fact is, if you’re cleaning a large amount of laundry, or even just small loads on a frequent basis, commercial grade appliances are cheaper in the long run.
· Our commercial laundry equipment represents a one-time investment, rather than relying on third party services to clean your fabrics and clothing articles. In time, this laundry equipment will essentially pay for itself through savings. Of course, it’s also much more practical to have this machinery on-site, as it allows you to better integrated it into your work processes.
PERSONAL CARD
Parameter
TYPE | XGQ-15FII | XGQ-20FII | XGQ-25FII | XGQ-30FII | XGQ-50FII | XGQ-70FII | XGQ-100FII | XGQ-130FII | |
CAPACITY | |||||||||
Drum capacity | kg | 15 | 20 | 25 | 30 | 50 | 70 | 100 | 130 |
Drum volume | L | 160 | 195 | 250 | 315 | 540 | 708 | 1010 | 1300 |
Number of drums | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
Number ofloading doors | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
Number of unloading doors | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
DRUM SPEED | |||||||||
Washing speed | rpm | 50 | 48 | 45 | 37 | 36 | 35 | 34 | 32 |
Highest spin speed | rpm | 800 | 780 | 750 | 750 | 720 | 700 | 680 | 635 |
G-force | rpm | 230 | 240 | 250 | 285 | 300 | 300 | 300 | 300 |
HEATING | |||||||||
Electric | kw | 14 | 18 | 21 | 21 | 42 | 46 | / | / |
Steam ratio | kg/kg | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 |
CONNECTIONS | |||||||||
Water inlet | ZG1.0" | ZG1.0" | ZG1.2" | ZG1.5" | ZG1.5" | ZG1.5" | ZG1.5" | ZG2.0" | |
Steam inlet | ZG3/4" | ZG3/4" | ZG3/4" | ZG1.0" | ZG1.0" | ZG1.0" | ZG1.0" | ZG1.5" | |
DIMENTIONS | |||||||||
Width | mm | 930 | 1000 | 1150 | 1460 | 1610 | 1650 | 1760 | 1950 |
Depth | mm | 1100 | 1170 | 1220 | 1440 | 1680 | 1960 | 2090 | 2220 |
Height | mm | 1530 | 1560 | 1600 | 1840 | 2040 | 2160 | 1970 | 2175 |
THE FACTORY
Located in the Shanghai, a beautiful city in China, Shanghai Gamesail washing machine CO., LTD owns many factory buildings, covering an area of 12000 square meters.
Gamesail has a researching and developing team with rich professional technology, among which are our technicians of over 20 years’ professional designing experience and internationally famous designing experts. Through learning from advanced international technology, we never stop the pace of innovation and have succeeded in designing the G series production with our own characteristics. This type of machine enjoys the superiority of advanced designs, low energy consumption, shorter washing period and will lead an industrial innovative trend.
Leading technology and complete production system are two footstones of us. As quality enjoys the best priority in Gamesail, we have set our goal as building the first rate quality, establishing scientific quality concept and have formulated strict quality management regulations. We have been certificated by ISO9001 international quality management system, European Union CE system, and ISO14001 environment management system. With superior quality, our product boasts its longer service life than other products in such field.
FAQ
1.Q:Are you a factory or trading company?
A: We are a factory.
2.Q:Where is your factory located?
A: Our factory is in Shanghai,China.
3.Q:What is the material of your products?
A: We are always high quality material and world famous components.
4.Q:How about quality control in your factory?
A: We are always paying great attentions to quality controlling from the beginning to the end.
5.Q:How about guarantee?
A: It's within 1 year after goods is discharged in the destination.
