Industry Clothes Dryer Hotel Washing Machine Heavy Laundry Machine

Large Image : Industry Clothes Dryer Hotel Washing Machine Heavy Laundry Machine Get Best Price

Product Details:

Place of Origin:	China Shanghai
Brand Name:	Gamesail
Certification:	CE,ISO9001,ISO14001,SGS
Model Number:	XGQ-FII

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	negotiable
Packaging Details:	Pallet or wooden case packing
Payment Terms:	D/P, D/A, T/T, L/C, Western Union, MoneyGram
Supply Ability:	200PCS/Month

Contact Now

Detailed Product Description

Capacity::	15kg-130kg	Loading Type:	Front Loading
Raw Material:	Stainless Steel 304	Heating::	Electric, Steam, Electric&Steam,Hot & Cold Water
Automatic:	Automatic & Manual	Voltage:	110v,220v,380v,400v,415v,440v
Packing:	Pallet Or Wooden Case	HS Code:	84502000
Suspension:	Full Suspension Shock Structure	Door:	Front And Single
High Light:	hotel laundry equipment , hotel laundry machines

Dryer Machine Industry Laundry Clothes Washing Dryer Machine Heavy Laundry Machine

Shanghai Gamesail Washing Machine Co.,ltd is your full service laundry equipment manufacturer. Our goal is to build and nurture a full partnership with you to solve any challenge you may have when it comes to your laundry business. We have a large support staff with the experience and knowledge necessary to address any needs you may have.

XGQ Series Industrial Washer

Save Steam

A traditional laundry machine relies on steam to act as the primary cleaning medium. Because of this, even the so-called “high-efficiency” models still consume bathfuls of steam with every wash cycle. A XGQ-G machine have 350G extract force which reduces energy consumption and 350G extraction equals less time in the dryer. Less drying time can save 20% steam consumption for dryer. With our steam-saving type GZZ-G dryer machine,it can save 40% steam consumption and reduce 50% drying time.The steam is recycled. Save 20% steam for washer,40% steam for dryer.

Sustainability

The efficiency of the XGQ-G machine makes it the ideal tool for ecologically-minded companies is an environment-friendly solution for your fabric washing needs. Plus, the GZZ-G dryer are steam re-usable and fully recyclable, allowing them to save the cost for clients.

Main Parts and Features

1.Internal Drum

Made of superior 304 stainless steel; Each internal drum has been put under dynamic balance test; Deviation of gravity center is less than 20g; Exquisite and durable.

2. Controller

Guangzhou Pump personally tailored this type of controller for Supersail with advanced philosophy and great convenience.

3. Spring Cushioning Structure (Patent Number: 200820056884.2)

Special Foundation is not required; Effective shock absorption can reach 95%; Moisture content of standard linen after dehydration will be less than 70%.

4. Electric Motor and other Parts

Our electric motor is Fuzhou specialized type; Our frequency Converters are purchased from oversea famous brands; Our belt is made by Samsung; Bearings are made by American TWB; The seal ring of the principal axis adopts imported fluororubber type.

PERSONAL CARD

Vincent
Phone:0086-18621994284
WeChat:0086-18621994284
Skype:0086-18621994284
WhatsApp:0086-18621994284
Facebook:0086-18621994284
E-mail: vincent.niu86@outlook.com
Vincent_niu@aliyun.com

PRODUCT FEATURES

Parameter

Type/Parameter	Unit	XGQ-30FII	XGQ-50FII	XGQ-70FII	XGQ-100FII	XGQ-130FII	XGQ-150FII
Type/Parameter	Unit	XGQ-30FII	XGQ-50FII	XGQ-70FII	XGQ-100FII	XGQ-130FII	XGQ-150FII
Washing Capacity	kg	30	50	70	100	130	150
Drum Size(diameter*depth)	mm	900*500	1065*610	1090*760	1210*880	1320*950	1460*920
Drum Volume	L	315	540	708	1010	1300	1520
Washing Speed	rpm	37	36	35	34	32	32
High Extractor Speed	rpm	750	720	700	680	635	630
Extractor G Value		285	300	300	300	300	300
Motor Power	kW	4	5.5	7.5	7.5	11	22
Inverter Power	kW	5.5	7.5	11	11	15	22
Electric Heating Power	kW	21	42	46	——	——	——
Steam Consumption Ratio	kg/kg	0.9	0.9	0.9	0.9	0.9	0.9
Water Inlet Pipe Diam	Inch	ZG1.5″	ZG1.5″	ZG1.5″	ZG1.5″	ZG2.0″	ZG2.0″
Steam Pipe Diam	Inch	ZG1.0″	ZG1.0″	ZG1.0″	ZG1.0″	ZG1.5″	ZG2.0″
Boundary Dimension
Width	mm	1460	1610	1650	1760	1950	1980
Depth	mm	1440	1680	1960	2090	2220	2500
Height	mm	1840	2040	2160	1970	2175	2190
Weight	kg	1600	2250	2800	3200	4100	4900

THE FACTORY

Located in the Shanghai, a beautiful city in China, Shanghai Gamesail washing machine CO., LTD owns many factory buildings, covering an area of 12000 square meters.

Energy Saving Philosophy

Gamesail has a researching and developing team with rich professional technology, among which are our technicians of over 20 years’ professional designing experience and internationally famous designing experts. Through learning from advanced international technology, we never stop the pace of innovation and have succeeded in designing the G series production with our own characteristics. This type of machine enjoys the superiority of advanced designs, low energy consumption, shorter washing period and will lead an industrial innovative trend.
Superior Quality

Leading technology and complete production system are two footstones of us. As quality enjoys the best priority in Gamesail, we have set our goal as building the first rate quality, establishing scientific quality concept and have formulated strict quality management regulations. We have been certificated by ISO9001 international quality management system, European Union CE system, and ISO14001 environment management system. With superior quality, our product boasts its longer service life than other products in such field.

Professional Service
With a number of professional talents of many years’ experience in developing, manufacturing, sales and service of washing machines, we provide superior and timely after sales service. In order to meet different needs of our customers, we provide professional integrated solutions to ensure the most benefits of customers with the least input and to develop together with them.

Competitive Price

Holding the tenet of sustainable development and win-win result with our cooperators, we always set our goal as: to be the first in cost-performance. Our products rank high in quality and service life, for which we are chosen by countless customers. However, our price is customer friendly, which ends in our superior cost-performance. That best answers why we enjoy great popularity in our customers.

Why Choose Gamesail

1. Supply you top quality products with competitive price under the same quality level,
different products according to your different market demands.

2. Strictly control the whole production process and guarantee punctual delivery, Test each
of our products one by one before packing to ensure the quality.

3. Supply you a good pre-sale, in-sale and after-sale service, We're not just working partners,
but also friends and family.

4. When you come to our factory, we will try our best to supply you all services to make you feel
like at home.

FAQ

1.How long have you engaged in this industry?
We have been engaged in this industry for more than 15 years, Our hot products sold at home and abroad by our own foreign trade department and some trading company.

2. Could you tell me how to put machine?
Please give us the size or drawing your laundry room,we will design layout according to it.

3. A dry clean shop need which machine?
Dry cleaning machine,ironing table,steam generator,clothes conveyor,universal press machine,can u buy perc or hydrocarbon from your local market?

4. A laundry need what kind of machine?
In general,we choose different machine according to washing capacity and laundry area,washer extractor,tumble dryer,sheets ironing machine,folding machine,laundry trolley are needed for most laundry.

5. We only have single phase,is it ok?
In general,single phase is ok for small machine,but big machine need 3 phase.

6.Are you a manufacturer or trading company?

We are manufacturer.

7.Where is your factory?

No.639 Kegong Road,Fengxian District,Shanghai China.
