XGQ - F Series Industrial Laundry Equipment , Front Loading Large Capacity Washing Machine
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Capacity:: | 15kg-150kg | Loading Type: | Front Loading |
|---|---|---|---|
| Raw Material: | Stainless Steel 304 | Heating:: | Electric, Steam, Electric&Steam,Hot & Cold Water |
| Automatic: | Automatic & Manual | Voltage: | 110v,220v,380v,400v,440v |
| Packing: | Pallet Or Wooden Case | HS Code: | 84502000 |
| Suspension: | Full Suspension Shock Structure | Door: | Front And Single |
| Highlight: | hotel laundry machines,hotel washer and dryer |
||
Full auto 5 star luxury hotels used 50kg hotel washing machines, laundry equipment
Shanghai Gamesail Washing Machine Co.,ltd is your full service laundry equipment manufacturer. Our goal is to build and nurture a full partnership with you to solve any challenge you may have when it comes to your laundry business. We have a large support staff with the experience and knowledge necessary to address any needs you may have.
XGQ Series Industrial Washer
Our XGQ line of Softmount Industrial Freestanding washer extractors provides industrial strength washer-extractors with unbeatable pricing. Optional one way tilting make loading and unloading simple and efficient. With capacities from 22 to 200 pounds (15 to 130kg), we have the right sizing for you application. High extraction speeds mean less time in the dryer, yielding tremendous energy and time savings.
· Standard 1 year warranty
· 350G extract force which reduces energy consumption and increases savings
· Advanced Microcomputer, PC programmable, programs transferred via USB
· 5 Compartment supply dispenser for dry and liquid chemicals
· 5 connections for automatic chemical injection
· All parts in contact with the wash solution made of stainless steel.
· Inverter drive - programmable variable speed
· Single motor drive
· Robust spring or Airbag suspension
· Programmable water levels
· Programmable water temperature
· Rear drain connection
Save Steam
A traditional laundry machine relies on steam to act as the primary cleaning medium. Because of this, even the so-called “high-efficiency” models still consume bathfuls of steam with every wash cycle. A XGQ-G machine have 350G extract force which reduces energy consumption and 350G extraction equals less time in the dryer. Less drying time can save 20% steam consumption for dryer. With our steam-saving type GZZ-G dryer machine,it can save 40% steam consumption and reduce 50% drying time.The steam is recycled. Save 20% steam for washer,40% steam for dryer.
Main Features
· Adopt touch-type programmable computer control system, it is highly automatic, safe, stability and anti-shock.
· Adopt touch-type programmable computer control system, it is highly automatic, safe, stability and anti-shock.
· Adopt the international latest complete suspension structure to reduce shock, Real meaing of free standing,No damage to machine while high spin.it can ensure an ideal anti-shock effect even on higher floors. Patented anti-vibration structure spring,shock absorption reaches to 95%(Patent no.200820056884.2)
· With fully-closed and rear-drainage structure,Large drain valves and two drain connections available.It is good for environmental protection.
· It is with a drum without compartment and single door structure convenivent to loading or unloading, and reduces the labor intensity and improves the clean level.
· The drum and case are both made of high quality stainless steel with the advantages of stain resistance and durability.Each drum tested by dynamic balance machine and the gravity deviation no more than 20g.
· We adopt world famous qualified parts suppliers.like Japan Yaskawa inverter,MIT V-belts,American TWB bearings,French Schneider electric parts,Imported Viton seal makes no leakage,and so on to ensure the high quality.
· We have got CE,IEC,ISO,SASO certificates.Our machines have been sold to USA, UK, Asia, Africa, Amecian, Canada, India and many other countries.
· Frequency controlled motor.the washing and extractor speed is adjustable.removable compartments Soap hoppers(above 30kg)
· USB port microprocessor enables to reprogram freely&easily by PC.
· We provide good pre-sales and after-sales service.We can make the laundry layout drawing for the clients. and lifelong technology conulting service.Easy access to all parts for maintenance.
· The machines heating way have electric heating, steam heating and cold & hot water types.
Contact
Vincent
Phone:0086-18621994284
WeChat:0086-18621994284
Skype:0086-18621994284
WhatsApp:0086-18621994284
Facebook:0086-18621994284
Email: vincent.niu86@outlook.com
vincent_niu@aliyun.com
PRODUCT FEATURES
Parameter
| TYPE | XGQ-15FII | XGQ-20FII | XGQ-25FII | XGQ-30FII | XGQ-50FII | XGQ-70FII | XGQ-100FII | XGQ-130FII | |
| CAPACITY | |||||||||
| Drum capacity | kg | 15 | 20 | 25 | 30 | 50 | 70 | 100 | 130 |
| Drum volume | L | 160 | 195 | 250 | 315 | 540 | 708 | 1010 | 1300 |
| Number of drums | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| Number ofloading doors | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| Number of unloading doors | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| DRUM SPEED | |||||||||
| Washing speed | rpm | 50 | 48 | 45 | 37 | 36 | 35 | 34 | 32 |
| Highest spin speed | rpm | 800 | 780 | 750 | 750 | 720 | 700 | 680 | 635 |
| G-force | rpm | 230 | 240 | 250 | 285 | 300 | 300 | 300 | 300 |
| HEATING | |||||||||
| Electric | kw | 14 | 18 | 21 | 21 | 42 | 46 | / | / |
| Steam ratio | kg/kg | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 |
| CONNECTIONS | |||||||||
| Water inlet | ZG1.0" | ZG1.0" | ZG1.2" | ZG1.5" | ZG1.5" | ZG1.5" | ZG1.5" | ZG2.0" | |
| Steam inlet | ZG3/4" | ZG3/4" | ZG3/4" | ZG1.0" | ZG1.0" | ZG1.0" | ZG1.0" | ZG1.5" | |
| DIMENTIONS | |||||||||
| Width | mm | 930 | 1000 | 1150 | 1460 | 1610 | 1650 | 1760 | 1950 |
| Depth | mm | 1100 | 1170 | 1220 | 1440 | 1680 | 1960 | 2090 | 2220 |
| Height | mm | 1530 | 1560 | 1600 | 1840 | 2040 | 2160 | 1970 | 2175 |
THE FACTORY
Located in the Shanghai, a beautiful city in China, Shanghai Gamesail washing machine CO., LTD owns many factory buildings, covering an area of 12000 square meters.
Energy Saving Philosophy
Gamesail has a researching and developing team with rich professional technology, among which are our technicians of over 20 years’ professional designing experience and internationally famous designing experts. Through learning from advanced international technology, we never stop the pace of innovation and have succeeded in designing the G series production with our own characteristics. This type of machine enjoys the superiority of advanced designs, low energy consumption, shorter washing period and will lead an industrial innovative trend.
Superior Quality
Leading technology and complete production system are two footstones of us. As quality enjoys the best priority in Gamesail, we have set our goal as building the first rate quality, establishing scientific quality concept and have formulated strict quality management regulations. We have been certificated by ISO9001 international quality management system, European Union CE system, and ISO14001 environment management system. With superior quality, our product boasts its longer service life than other products in such field.
Professional Service
With a number of professional talents of many years’ experience in developing, manufacturing, sales and service of washing machines, we provide superior and timely after sales service. In order to meet different needs of our customers, we provide professional integrated solutions to ensure the most benefits of customers with the least input and to develop together with them.
Competitive Price
Holding the tenet of sustainable development and win-win result with our cooperators, we always set our goal as: to be the first in cost-performance. Our products rank high in quality and service life, for which we are chosen by countless customers. However, our price is customer friendly, which ends in our superior cost-performance. That best answers why we enjoy great popularity in our customers.
Why Choose Gamesail
1. Supply you top quality products with competitive price under the same quality level,
different products according to your different market demands.
2. Strictly control the whole production process and guarantee punctual delivery, Test each
of our products one by one before packing to ensure the quality.
3. Supply you a good pre-sale, in-sale and after-sale service, We're not just working partners,
but also friends and family.
4. When you come to our factory, we will try our best to supply you all services to make you feel
like at home.
FAQ
1.Q:Are you a factory or trading company?
A: We are a factory.
2.Q:Where is your factory located?
A: Our factory is in Shanghai,China.
3.Q:What is the material of your products?
A: We are always high quality material and world famous components.
4.Q:How about quality control in your factory?
A: We are always paying great attentions to quality controlling from the beginning to the end.
5.Q:How about guarantee?
A: It's within 1 year after goods is discharged in the destination.
