Product Details:
Payment & Shipping Terms:
|
Capacity:: | 15kg-150kg | Loading Type: | Front Loading |
---|---|---|---|
Raw Material: | Stainless Steel 304 | Heating:: | Electric, Steam, Electric&Steam,Hot & Cold Water |
Voltage: | 110v,220v,380v,400v,440v | Packing: | Pallet Or Wooden Case |
Suspension: | Full Suspension Shock Structure | Door: | Front And Single |
Highlight: | commercial washer dryer,large capacity washing machine |
· Commercial Laundry Equipment
· Gamesail supply a wide range of commercial laundry equipment for industrial and commercial sectors, including washers, dryers, ironers and spare parts for most manufacturers and model ranges.
·VIEW OUR COMMERCIAL LAUNDRY EQUIPMENT RANGE
·
The Right Product For You
· Different companies have different needs, so the right appliance is essential. For example, traditional washing machines are great for handling large loads, while the likes of barrier washers can provide safe infection control services. If you’re not sure what you need, we can help you find the right tools for the job, choosing from our range of:
· Washing machines,
· Tumble dryers
· Barrier washers
· Ironers
· Folders
· Hydro extractors
· Cloth finishers
· Similarly, you also need to consider the size and dimensions of your work space. We have plenty of experience helping companies large and small. If you have space limitations, we can advise you right options, for instance, to help maximise the productivity and efficiency from every possible area.
·
The Power Of On-site Commercial Laundry Equipment
· If you haven’t invested in commercial laundry equipment yet, you may be wondering why it’s so beneficial. The fact is, if you’re cleaning a large amount of laundry, or even just small loads on a frequent basis, commercial grade appliances are cheaper in the long run.
· Our commercial laundry equipment represents a one-time investment, rather than relying on third party services to clean your fabrics and clothing articles. In time, this laundry equipment will essentially pay for itself through savings. Of course, it’s also much more practical to have this machinery on-site, as it allows you to better integrated it into your work processes.
·
The Right Quality
· We offer best cost performance commercial laundry equipment, helping you to meet all of your needs regardless of your budget. In everything we offer, we can provide after sales agreements as well. This is something many companies are unsure of, yet we have the ideal solution.
· Not only do we provide high quality products every time, we can also agree on maintenance costs upfront, so you always know how much something might cost. If this is something you are concerned about, please get in touch.
· Whether you’re a small firm or a large chain, the right laundry is vital. It keeps your supplies clean and your staff uniforms looking at their best. Investing in commercial grade laundry equipment is an effective way to maintain quality across your entire business. Furthermore, it will save costs from relying on other companies and old equipment. If you’re looking to improve your laundry and washing operations, Gamesail has the appliances for you.
PERSONAL CARD
Parameter
TYPE | XGQ-15FII | XGQ-20FII | XGQ-25FII | XGQ-30FII | XGQ-50FII | XGQ-70FII | XGQ-100FII | XGQ-130FII | |
CAPACITY | |||||||||
Drum capacity | kg | 15 | 20 | 25 | 30 | 50 | 70 | 100 | 130 |
Drum volume | L | 160 | 195 | 250 | 315 | 540 | 708 | 1010 | 1300 |
Number of drums | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
Number ofloading doors | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
Number of unloading doors | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
DRUM SPEED | |||||||||
Washing speed | rpm | 50 | 48 | 45 | 37 | 36 | 35 | 34 | 32 |
Highest spin speed | rpm | 800 | 780 | 750 | 750 | 720 | 700 | 680 | 635 |
G-force | rpm | 230 | 240 | 250 | 285 | 300 | 300 | 300 | 300 |
HEATING | |||||||||
Electric | kw | 14 | 18 | 21 | 21 | 42 | 46 | / | / |
Steam ratio | kg/kg | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 |
CONNECTIONS | |||||||||
Water inlet | ZG1.0" | ZG1.0" | ZG1.2" | ZG1.5" | ZG1.5" | ZG1.5" | ZG1.5" | ZG2.0" | |
Steam inlet | ZG3/4" | ZG3/4" | ZG3/4" | ZG1.0" | ZG1.0" | ZG1.0" | ZG1.0" | ZG1.5" | |
DIMENTIONS | |||||||||
Width | mm | 930 | 1000 | 1150 | 1460 | 1610 | 1650 | 1760 | 1950 |
Depth | mm | 1100 | 1170 | 1220 | 1440 | 1680 | 1960 | 2090 | 2220 |
Height | mm | 1530 | 1560 | 1600 | 1840 | 2040 | 2160 | 1970 | 2175 |
THE FACTORY
Located in the Shanghai, a beautiful city in China, Shanghai Gamesail washing machine CO., LTD owns many factory buildings, covering an area of 12000 square meters.
Founded in early 2002, with years’ efforts, we have developed a variety of machine series including water washing, drying, ironing, dry cleaning and other related auxiliary equipment, making the total variety exceeding 70. We are capable of providing diversified solutions to our customers to meet their different needs.
With a number of professional talents of many years’ experience in developing, manufacturing, sales and service of washing machines, we provide superior and timely after sales service. In order to meet different needs of our customers, we provide professional integrated solutions to ensure the most benefits of customers with the least input and to develop together with them.
Holding the tenet of sustainable development and win-win result with our cooperators, we always set our goal as: to be the first in cost-performance. Our products rank high in quality and service life, for which we are chosen by countless customers. However, our price is customer friendly, which ends in our superior cost-performance. That best answers why we enjoy great popularity in our customers.
Why Choose Gamesail
1. Supply you top quality products with competitive price under the same quality level,
different products according to your different market demands.
2. Strictly control the whole production process and guarantee punctual delivery, Test each
of our products one by one before packing to ensure the quality.
3. Supply you a good pre-sale, in-sale and after-sale service, We're not just working partners,
but also friends and family.
4. When you come to our factory, we will try our best to supply you all services to make you feel
like at home.
